Standard: ASTM / ASME SB 111 / 466/ASTM A403
Grade: UNS NO. C 10100, 10200, 10300, 10800, 12000, 12200, 70600 ( CU -NI- 90/10) , 71500

( CU -NI- 70/30).

Buttweld Cap Fitting

The function of a Buttweld End Cap Fitting is to block off the end of a line in a piping system. The Buttweld

Cap is fitted by placing the end cap over the open line and welding around the joint.

Buttweld Stub End Fitting

Stub Ends are installed in pairs and mated together with two Lap Joint Flanges. The surface of the stub end

has a phonographic serrated gasket surface which prevents leakage at the joint. Using stub ends allows

sections of the line to be opened for cleaning, inspection or quick replacement etc, without the need to re-weld.

Eccentric / Concentric Reducer Fitting

There are two options available, of Concentric Reducer or Eccentric Reducer.

An Eccentric Reducer, also called a Bell reducer, has two female (inside) threads of different sizes with centers

so designed that when they are joined, the two pieces of pipe are not in line with each other, but they can be

installed so as to provide optimum drainage of the line.

The fitting is designed with the smaller outlet off center to the larger end, allowing it to align with only one side

of the inlet. The reducer fittings are designed to be welded with ease and offer superior strength and leak

resistance.

Eccentric Reducer must be installed with straight side up to prevent trapping air at the pump suction. They are

designed to allow simple connection of different sized pipes. These can be used as pipe reducers, flexible

connectors and vibration eliminators.

Eccentric Reducers eliminate noise and isolate vibration in the pipeline, reduces stress, eliminates electrolysis

and protects against start-up surges.

A Concentric Reducer joins the tube sections on the same axis. They connect unequal size pipes that have a

common centerline and are used for TC transitions in vertical tubing.

A Concentric Reducer has different size ends to mate hose or tubing of different diameter that joins tube

sections on the same axis. Since virtually all piping systems go through changes in diameter either in the run

or at the equipment connections, a reducer serves the dual purpose of changing the piping diameter and at the

same time that of handling the expansion, misalignment or vibration problem.

While there are published transition sizes and face to face dimensions, it is seldom that the cataloged sizes

refer to what is required on the jobsite. Hence, the face to face dimensions as well as the two flange sizes are

varied to fit the application. Thus, Custom reducers are easily manufactured as per the specifications.

1.1.1 Dimensions for Buttweld Fittings:

- BS 1640/ANSI - ASME B16.9 - B16.28 - B16.25
- Seamless, EFW, ERW, DSAW and Forged

1.1.2 Material Grades for Buttweld Fittings

All buttweld fittings are available in the following material grades:

· Stainless Steel

· A403 304/L 310 316/L 321/H 347/H 410440 904L

· Carbon Steel

· A234 WPB, WPC

· Low Temperature Steel

· A420 WPL6, WPL3

· Alloy Steel

· A234 WP1, WP5, WP9, WP11, WP12, WP22, WP91

· High Yield

· WPHY42, 52, 60, 65, 70

· Duplex & Super Duplex

· A815 UNS 31803, UNS 31254, UNS S32750 UNS S32760

· Nickel Alloys

· 200, 400, K500, 600, 625, 800, 825

· Alloys

· ALLOY 20 ALLOY C ALLOY C276 ALLOY B2

· Aluminium

· 5083, 5154, 5251, 6061, 6063, 6082

· Unusual Grades

· Bronze, Brass, Copper

· Cupro Nickel

Titanium

MARILOY S400/TPY JIS G 3454/57 ELBOW 90º LR Butt Weld Fittings CONCENTRIC REDUCER

1.1.1 Packaging & Delivery

Packaging Details:

Wooden cases, pallets, nylon bags or according to the customers' requirements

Delivery Detail:

10-100 days depending on quantity

ASTM A234 WP5 butt welded tee

Tee Type

Equal tee, reducing tee,lateral tee, BW/butt weld tee, TH/threaded tee,

SW/socket weld tee, seamless tee

Standard

ASTM B16.9, ASTM B16.11, ASTM B16.5;

JIS B2311,JIS B2312,JIS B2313,JIS B2316;

MSS SP-43, MSS SP-95, MSS SP-75, MSS SP-79;

ISO 3419,ISO 5251,DIN 2615

SY/T 0510, SH 3408, SH3410

Size

1/2''-48''(Butt-welding and seamless);1/8''-4''(Threaded and socket-welding);16''~72''(Welded)

Wall thickness

Sch5~Sch160XXS

Manufacturing process

Push, Press, Forge, Cast, etc.

Material

Carbon steel

Stainless steel

Alloy steel

Duplex steel

Nickel alloy steel

Carbon steel tee, stainless steel tee, alloy steel tee

ASTM A234 WPB,

ASTM A420 WPL6, WPL3;

ASTM A105 WPB;

ASTM A106;

ASTM A350 LF2,

DIN St37, St45.8, St52.4,St.35.8,St.35.8/I

ASTM A333 GR.6,

ASTM A860 WPHY 70, WPHY 65, WPHY 60, WPHY 52,WPHY 46,WPHY 42,

API 5L GRB, X60, X65, X42,X52,

ASTM A403 WP304, A403 WP304L, A403 WP316, A403 WP316L

A403 WP321

ASTM A182 F 304, 304L,316, 316L,904L

ASTM A234 WP12, A234 WP11, A234 WP22, A234 WP5, A234 WP9

A420 WPL8, A420 WPL9

ASTM A335 P5, P9, P11, P12, P22, P91

ASTM A213

ASTM A182 F5,F11,F22,F91

ASTM A182 F51/SAF 2205/S31803,F53/SAF 2507/S32750,F60/UNS S32205,

Alloy 200/nickel 200/UNS S2200,Alloy 400/monel 400/UNS 4400,

Alloy 600/Inconel 600/UNS,

6600,Alloy 201/nickel 201/UNS S2201,Alloy 625/Inconel 625/UNS 6625/N

S336,Alloy 800/Incoloy 800/UNS S8800,

PACKING

Wooden cases, pallets, nylon bags or according to the customers'

requirements

MOQ

1pcs

Delivery time

10-100 days depending on quantity

Payment terms

L/C,T/T

Shipment

FOB Tianjin/Shanghai, CFR, CIF, etc

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Remarks

Other materials and drawings are available.

CONCENTRIC REDUCER

Products

Elbow,bend equal /reduce tee,concentric/eccentric reducer , cap,flange

Size

Seamless(SMLS) Elbows : 1/2"-24" ,DN15-DN600

Butt Welded Elbows (seam) :24”-72",DN600-DN1800

Type

LR 30,45,60,90,180 degree SR 30,45,60,90,180 degree

1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.

Thickness

SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS

Standard

ASME,ANSI B16.9;

DIN2605,2615,2616,2617,

JIS B2311 ,2312,2313;

EN 10253-1 ,EN 10253-2

Material

ASTM

Carbon steel(ASTM A234WPB,,A234WPC,A420WPL6.

Stainless steel(ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti, 00Cr19Ni10,00Cr17Ni14Mo2, ect.)

Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,

A420WPL6,A420WPL3

DIN

Carbon steel:St37.0,St35.8,St45.8

Stainless steel:1.4301,1.4306,1.4401,1.4571

Alloy steel:1.7335,1.7380,1.0488(1.0566)

JIS

Carbon steel:PG370,PT410

Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321

Alloy steel:PA22,PA23,PA24,PA25,PL380

GB

10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,

12CrMo, 12CrMoG, 12Cr1Mo

Surface treatment

Transparent oil, rust-proof black oil or hot galvanized

Packing

In wooded cases or pallets, or as for clients' requirements

Applications

Petroleum, chemical, machinery, boiler,electric power, shipbuilding, papermaking, construction, etc

Certification

API and ISO 9001:2000

Min order

1 piece

Delivery time

7 after receipt of advanced payment ,have stock ~

Payment Term

T/T ,West Union,

Trade Term

FOB,CIF,CFR(30% down payment in advance, balance should before shipment)

Address

Mengcun Country, Cangzhou City,Hebei Province,China

Name
SCH40 90 degree carbon steel elbow

Products

Elbow,bend equal /reduce tee,concentric/eccentric reducer , cap,flange

Size

Seamless(SMLS) Elbows : 1/2"-24" ,DN15-DN600

Butt Welded Elbows (seam) :24”-72",DN600-DN1800

Type

LR 30,45,60,90,180 degree SR 30,45,60,90,180 degree

1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.

Thickness

SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS

Standard

ASME,ANSI B16.9;

DIN2605,2615,2616,2617,

JIS B2311 ,2312,2313;

EN 10253-1 ,EN 10253-2

Material

ASTM

Carbon steel(ASTM A234WPB,,A234WPC,A420WPL6.

Stainless steel(ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti, 00Cr19Ni10,00Cr17Ni14Mo2, ect.)

Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,

A420WPL6,A420WPL3

DIN

Carbon steel:St37.0,St35.8,St45.8

Stainless steel:1.4301,1.4306,1.4401,1.4571

Alloy steel:1.7335,1.7380,1.0488(1.0566)

JIS

Carbon steel:PG370,PT410

Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321

Alloy steel:PA22,PA23,PA24,PA25,PL380

GB

10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,

12CrMo, 12CrMoG, 12Cr1Mo

Surface treatment

Transparent oil, rust-proof black oil or hot galvanized

Packing

In wooded cases or pallets, or as for clients' requirements

Applications

Petroleum, chemical, machinery, boiler,electric power, shipbuilding, papermaking, construction, etc

Certification

API and ISO 9001:2000

Min order

1 piece

Delivery time

7 after receipt of advanced payment ,have stock ~

Payment Term

T/T ,West Union,

Trade Term

FOB,CIF,CFR(30% down payment in advance, balance should before shipment)

Address

Shanghai China

Our products :carbon steel ,alloy steel ,stainless steel pipes and pipe fittings

such as: long/short radius elbows(EL/ES),straight / reducing tee(TC/TR) ,SO ,WN,PL,BL,SW,TH flanges,pipe end cap,eccentric/concentric reducers ;sprial welded steel pipe (SSAW),seamless steel pipe (SMLS) ,and LSAW pipe!

The sizes:
